humiDisk is a small but robust centrifugal humidifier designed for industrial and commercial applications, for cold rooms and fruits/vegetables storage rooms.
humiDisk uses a rotating disk to atomise the water and transform it into millions of tiny drops that, pushed by an integrated fan, are introduced into the environment where they evaporate, humidifying and cooling the air.
humiDisk is a humidification system that is simple, economical and easy to maintain, with energy consumption of only 220 Watts for the 6.5Kg/h model and 31 Watts for a 1Kg/h model.
humiDisk may work with drinkable water from the aqueduct or with treated water. Please note that the quantity and quality of the minerals dissolved in water influence the frequence of regular maintenance operations and the quantity of dust generated by the humiDisk.
For an optimal usage we advise to utilize demineralized water (not softened water because this do not reduce the mineral content of the water); in every case, please follow your local normatives, such as the UNI8884.
The advantages of humiDisk humidifiers are:
- Simplicity: only the 230Vac power supply and the water loading and unloading line can be operated, and control via On/Off contact
- Igenically safe: very small tank of water (only 55ml), machine wash cycle (washing at each cycle start with CAREL electrical panels) and emptying at the end of the cycle.
- Modularity: it is possible to control 1 or 2 humiDisk65 in parallel by means of a control panel or up to 10 humiDisk10 via the CAREL humidistat.
Brochure of the CAREL humiDisk in PDF format.
